XAF 600-2,000 CFM Upflow/Downflow Indoor Coil

Fully cased, "A" coil design upflow and downflow unit

Coil MaxAlloy™ coil
Configuration Fully cased, with field-installed or factory-installed TXV available
Back to Top

QUALITY STARTS ON THE INSIDE

Luxaire® XAF Cased Up/Downflow Aluminum Indoor Coils are fully cased and designed for upflow and downflow applications. These units feature a new, “A” coil design and are made to match with Luxaire® furnaces to improve system efficiency. The MaxAlloy™ aluminum indoor coils are specially engineered to handle demanding air conditioner and heat pump duty. Combined with staggered tube rows that provide proper moisture removal, this smart design provides reliable, efficient performance. Designed for compliance with upcoming Department of Energy (DOE) 2023 regulations, XAF indoor evaporator coils will help your system meet more stringent minimum efficiency standards.
QUALITY STARTS ON THE INSIDE

Features

  • Long-life MaxAlloy™ aluminum coil provides lasting reliability
  • Provides proper moisture removal with staggered tube rows
  • Handles demanding AC or heat pump duty
  • Streamlined “A” coil design for maximum efficiency and performance
  • TXV kits available, featuring nonbraze, bolt-on connectors for quick and easy installation
  • Delivers optimized efficiency when partnered with matching Luxaire® furnaces

Benefits

Lower Cost Of Ownership
LOWER COST OF OWNERSHIP

Through smart “A” Coil design and advanced Max Alloy™ aluminum materials, the XAF indoor coil can reduce total cost of ownership through long-lasting reliability.

Reliable Support
RELIABLE SUPPORT

Our Certified Comfort Expert™ contractors make sure your XAF indoor coil is installed and serviced correctly from day one.

Confidence Guaranteed
CONFIDENCE GUARANTEED

A 10-year Parts Limited Warranty ensures years of dependability with industry-leading quality.

DOE 2023 CERTIFIED

The Department of Energy’s newest efficiency standards take effect in January 2023. XAF indoor evaporator coils are designed to meet these standards, are DOE 2023 certified and will help your system meet these stringent requirements. Learn more about DOE 2023 standards on our DOE 2023 page.
Learn About DOE 2023

WARRANTY

With a Luxaire® residential system, comfort is more than a feeling – it’s a promise. Because Luxaire® home comfort systems are built to the highest standards and backed by the best warranties.
Register Your Warranty

Technical Specification

Tonnage Range 1.5-5 tons Capacity 600-2,000 CFM
Position Upflow/downflow design Parts Warranty Code 10-year Parts Limited Warranty*
*Must be registered online within 90 days of installation. If not registered within 90 days, the parts warranty reverts to a 5-year Limited Warranty.
